Developed in 1952 at the Naval Research Laboratory, the DWT (Drop Weight Test), also known as the Pellini Test, is a test method for determining the Nil Ductility Transition Temperature (NDT) of ferritic steels. This method plays a crucial role in assessing the fracture resistance of steel materials, especially for use in demanding environments such as shipbuilding, offshore structures and natural gas transportation systems. Let’s take a closer look at the origin, performance and importance of the DWT test, as well as the exact standards and applications for DWT-tested steels.
Aim and purpose of the DWT test: What is tested?
The DWT test is used to determine the crack arrest temperature (nil ductility transition temperature, NDT) of ferritic steels. The NDT temperature is the lowest temperature at which a steel still has sufficient toughness to prevent cracking. In addition to purely determining the temperature, the DWT test can also be used to evaluate the toughness of steels under various loading conditions, such as tensile or bending loads.
Performing the DWT test: A drop weight as a test method
For the DWT test, a drop weight with a mass of 4 to 4,000 kg is dropped from a certain height onto a sample of ferritic steel. The steel sample, which has a rectangular shape with a central notch, is loaded by the drop weight, with the notch acting as a crack initiator. The drop weight test is carried out under controlled climatic conditions to keep the temperature constant. By comparing the temperature of different samples, the NDT temperature – the temperature at which a crack propagates through the material – can be accurately determined.
Results of the DWT test: NDT temperature and penetration depth of the crack
The DWT test provides two main parameters:
- NDT temperature: The lowest temperature at which the material can still stop crack propagation.
- Penetration depth of the crack: This value shows the toughness of the material at a certain temperature.
Why is the DWT test important for the industry?
The NDT temperature is a key factor in determining the operating temperatures for ferritic steel components, especially in safety-critical areas such as pipelines and tanks. The DWT test is therefore of great importance for material testing and quality assurance in industries where fracture safety and temperature resistance play a decisive role, such as the oil and gas industry, shipbuilding and offshore facilities.
Norms and standards for the DWT test
There are two main standards for carrying out the DWT test:
- ASTM E208: (Standard test method for conducting drop-weight test to determine NDTT of ferritic steels)This standard, published in 2020, specifies more specific requirements for specimen size, impact energy and temperature ranges and is mainly used in the USA.
- SEP 1325: An older standard from 1964, which is used worldwide and is specifically designed for the W. S. Pellini test.
For which steel grades is the DWT test relevant?
The DWT test is primarily used for shipbuilding steels and offshore steels such as EH36 and NV36 as well as for steels in accordance with EN 10225. These steels are often used in extreme environments with high fracture resistance requirements.
DWT-tested steels are used in a wide range of industries, including:
- Transportation systems for liquid and gaseous fuels: Pipelines and tanks for crude oil and natural gas
- Offshore and shipbuilding: materials for drilling rigs, ships and other offshore constructions
- Critical infrastructure: Applications where temperature resistance and crack resistance are essential
By complying with defined standards and being used in safety-critical areas, the DWT test makes a decisive contribution to quality assurance and extending the service life of steels in demanding industries.
